Soft70 GEN2 Fixed Trim

Soft70 GEN2 fixed downlight. Available with standard trim kit or trimless kits for full skim, partial skim, or wood/stone ceilings. Available in both White or black and premium plated choices.

This product can accommodate a wide choice of LED light sources including our LED50 ONE family of modules and retrofit MR16 & GU10 LED lamps.

All Soft70 GEN2 downlights have been tested and approved to EN 1363-1:2020 and EN 1365-2:2014 for 60 minutes Fire Rating . To be ordered with the correct fire rating code.

Specification

Aperture:Ø 70mm
Adjustable :No
Overall Dimension:Ø 90mm
First Fix Requirement:Yes
Ceiling Cut-Out:Ø 79mm
Ceiling Thickness:15-28mm max
Ingress Protection :IP20 - IP65

Available light sources

Light source: LED50 ONE QUANTUM HE

Introducing the LED50 ONE Quantum High Efficacy series. Choice of 3 colour temperatures and 4 beam options. Designed to run at 200mA. Fully dimmable with an appropriate driver.

* For delivered lumen, refer to the luminaire data sheet.

LED Power:6.6W
Source Luminous Output*:1088-1187lm
Drive Current:200mA
Input Voltage:33V
CCT:2700K/3000K/4000K
Beam Option:NF/MF/FL/WFL
CRI:≥90 CRI
Dimming Options:Phase, 0-10V, 1-10V, DALI and Bluetooth

Product Code: SF70200

Light source: LED50 ONE QUANTUM HO

Introducing the LED50 ONE Quantum High Output series. Choice of 3 colour temperatures and 4 beam options. Designed to run at 350mA. Fully dimmable with an appropriate driver.

* For delivered lumen, refer to the luminaire data sheet.

LED Power:11.9W
Source Luminous Output*:1793-1899lm
Drive Current:350mA
Input Voltage:34V
CCT:2700K/3000K/4000K
Beam Option:NF/MF/FL/WFL
CRI:≥90 CRI
Dimming Options:Phase, 0-10V, 1-10V, DALI and Bluetooth

Product Code: SF70200

Light source: LED50 ONE GEN3

Introducing the LED50 ONE GEN3 - the latest evolution in our popular LED50 series. Choice of 5 colour temperatures and 4 beam options. Designed to run at 350mA. Fully dimmable with an appropriate driver.

* For delivered lumens, refer to the luminaire data sheet.

Power:12.6W
Luminous Output:1108-1258lm
Drive Current:350mA
Input Voltage:36V
CCT:2200K/2400K/2700K/3000K/4000K
Beam Option:SP/MF/FL/WFL
CRI:>90 CRI
Lifetime:L70 B10 105,000hrs @ Ta 25°C
Dimming Options: Phase, 0-10V, 1-10V, DALI and Bluetooth

Product Code: SF70200
