Micro40 Square Edge Trim

Micro40 Square Edge Trim fixed miniature downlight with black anti glare edge baffle. Available in both White and Black finishes as standard.

Micro40 family utilises the XPG2 LED in two colour options 2700K and 3000K and 4 beam angles - 15°, 25°, 30° and elliptical beam 18° x 33°.

Products sold into North America are assembled, warehoused and shipped by Lucent Lighting Incorporated located in New York.

Specification

  • Overall Dimension:1.57" x 1.57"
  • Overall Height:1.25"
  • Ceiling Cut Out:1.41" x 1.41"
  • Ceiling Thickness:0.59"
  • Ingress Protection:IP44

Available light sources

Light source: Micro40 LED

Micro40 Integral LED

  • LED Power:1.5W
  • Luminous Output:Please refer to specification sheet
  • Drive Current: 500mA
  • Input Voltage:3V
  • CCT:2700K/3000K/4000K
  • Beam Option:15°/25°/30°/18°x33°
  • CRI:90 CRI
  • Dimming Options:Phase, 0-10V, 1-10V, DALI and Bluetooth

Product Code: M40-SE-TR
