Micro40 Disc

Micro40 Disc round fixed miniature downlight with black anti glare sheild. Available in both White and Black finishes as standard.

Micro40 Disc utilises the XPE2 LED in two colour options 2700K and 3000K and 2 beam angles - 25° and 40°.

Products sold into North America are assembled, warehoused and shipped by Lucent Lighting Incorporated located in New York.

Specification

  • Overall Dimension:Ø1.57"
  • Overall Height:0.83"
  • Ceiling Cut Out:Ø1.06"
  • Ceiling Thickness:10mm MAX
  • Ingress Protection:Dry

Available light sources

Light source: Micro40 Disc

Micro40 Disc Integral LED

  • LED Power:Max. 1.5W
  • Luminous Output:Please refer to specification sheet
  • Drive Current:Max. 500mA
  • Input Voltage:3V
  • CCT:2700K/3000K
  • Beam Option:25°/40°
  • CRI:90 CRI
  • Dimming Options:Phase, 0-10V, 1-10V, DALI and Bluetooth

Product Code: AM40-MD
